PhlatLight ? DK-105T Series Development Kit Manual
4. Operating Instructions
Note: All pin 1 connectors are the positive terminal. All pin 2 connectors are the ground
terminal.
To operate, follow the instructions below:
1) Select the jumper settings for desired LED current as shown in Table 1.
2) Select the jumper setting for the ENABLE feature as shown in Table 2.
3) Select the jumper setting for the Synjet Control feature as shown in Table 3.
4) Connect J7 to the SST LED
5) If desired, connect 0-10V signal source to J6
6) If desired, connect J10 to the Synjet control
7) If desired, connect J9 to Synjet Power
8) Connect J1 to 12V power supply and turn on power supply.
Table 1: LED Current Selection
J8 J5
Installed Installed
Not installed Installed
Installed Not installed
Not installed Not installed
Table 2: LED Enable Selection
J3 Mode
Not installed Enable LED
Installed Disable LED
Table 3: Synjet Control Selection
J11 J12
Not installed Not installed
Not installed Installed
Installed Not Installed
Installed Installed
Refer to the schematic diagram below.
960032 Rev A ? Luminus Devices, Inc. All rights reserved.
LED Current
1.75A
3.15A
5.00A
Do not use
Mode
Standard
Silent
High
Off
Page 5
